Descriere
Designed to provide low cogging torque and smooth operation, the NX Series brushless servo motors from Parker combine exceptional precision and motion quality, high dynamic performances and very compact dimensions. A large set of torque/speed characteristics, options and customization possibilities are available, making NX Series synchronous servo motors the ideal solution for most servo system applications. The sensorless version of NX Series servo motor has been designed to offer a cost effective brushless solution in association with the Parker SSD AC650S drives. Controlled without feedback sensor, NX Series servo motors are an innovative, compact, performant and highly efficient alternative to traditional induction motors.
Markets:
• Factory Automation
• Packaging Machinery
• Food & Beverage
• Miscellaneous Industrial
• Miscellaneous Manufacturing
• Lab/Diagnostic
• Life Sciences
• Pharma
Features/Benefits:
• High precision and motion quality
• High dynamic performance
• Low cogging torque / Smooth operation
• Compact dimensions and robustness
• Large set of options and customization possibilities
• CE and UL marking certification available
Applications:
• Machine tools axis
• Packaging machinery
• Robot applications
• Special machinery
Technical Specifications:
– Motor Type : Permanent magnet synchronous brushless servo motor
– Rotor Design : Rotor with concentrated-flux rare earth magnets
– Number of Poles : 10
– Torque Range : 2 – 90 Nm
– Speed Range : 0 – 7000 min-1
– Mounting : Flange with smooth holes
– Shaft End : Plain keyed shaft / Plain smooth shaft (option)
– Cooling : Natural Convection / Forced Ventilation (NX860V only) / Water Cooled (NX860W only)
– Protection Level (IEC60034-5) : IP64 (standard) / IP65 (option) / IP44 (ventilated version)
– Feedback sensors : Resolver / Absolute Encoder / Hiperface Absolute Encoder
– Other options : Brake / Thermal Protection (PTC, thermo switch or KTY)
– Marking : CE / UL
– Voltage Supply : 230 / 400-480 VAC
– Temperature Class (IEC60034-1) : CE – Class F / UL Class F (NX3 – 8)
– Connection : Connectors / Flying Cables / Terminal Box (NX860V)
Dane techniczne
| Stopień ochrony przed wnikaniem: | IP64, IP65, IP44 |
| Typ wału: | Keyway, Smooth |
| Zgodny napęd Parker: | SLVD-N, PSD1, AC890, AC30, Compax3 |
| Metoda chłodzenia: | Air-Cooled / Forced Ventilation (NX860V), Water-Cooled (NX860W), Air-Cooled / Natural Convection |
| Maksymalna prędkość wyjściowa: | up to 10000 RPM |
| Typ montażu: | > 100 to 200 mm (PCD), > 50 to 100 mm (PCD), 1 to 50 mm (PCD), > 100 to 200 mm (Pilot Ø), > 50 to 100 mm (Pilot Ø) |
| Rozmiar wału: | > 30 to 40 mm, > 1 to 15 mm, > 20 to 30 mm, > 15 to 20 mm |
| Typ sprzężenia zwrotnego: | Absolute Single-turn HIPERFACE DSL® Encoder, Absolute Multi-turn HIPERFACE DSL® Encoder, Absolute Single-turn SinCos/HIPERFACE Encoder, Absolute Multi-turn SinCos/HIPERFACE Encoder, Without Sensor (sensorless), Resolver |
| Technologia: | Electromechanical |
| Seria produktu: | NX |
| Temperatura robocza: | -15 to 40 °C (-40°C on request), 5 to 104 °F (-40°F on request) |
| Rozmiar ramy: | 56 mm, 70 mm, 92 mm, 120 mm, 155 mm |
| Zgodność ze specyfikacjami: | UL/cUL, CE |
| Typ produktu: | Electric Motor |
| Rodzaj produktu: | Brushless Servo |
| Napięcie wejściowe: | 400 to 480 VAC, 230 VAC |
| Moment obrotowy w trybie pracy ciągłej: | 2 to 90 Nm, 18 to 797 lb-inch |
| Szczytowy moment obrotowy: | 6.6 to 137 Nm, 58 to 1212 lb-inch |
| Prędkość znamionowa: | 0 to 7000 RPM |
| Hamulec podtrzymujący w zestawie: | Optional |
